Solid State Logic SSL18
Product information "Solid State Logic SSL18"
For over 40 years, Solid State Logic audio tools have shaped countless hits and award-winning music productions around the world. With the SSL 18, this know-how now arrives in your personal studio as the first "High Performance Rack-Interface".
A new generation of high-quality 32-bit converters, eight powerful SSL microphone preamps, an advanced digital mixer, the legendary Legacy '4K' switch for a touch of analogue "glamour" and a complete set of digital inputs and outputs — whether you record, produce or mix, the SSL 18 improves your workflow while increasing the creativity and audio quality of your work.
The SSL18 feature set is rounded off by a configurable monitor section, comfortable talkback facilities, exemplary studio environment management via the free SSL 360° software and a comprehensive software package with everything your heart desires.
- 26 In / 28 Out
- 32-bit / 192 kHz converters
- +24 dBu operating level for all inputs and outputs
- 120 dB dynamic range on all inputs and the headphone outputs
- 125 dB dynamic range on the monitor and line outputs
- 8 high-quality microphone preamps: 67 dB gain range, -130.5 dBu EIN, +48V, 120 dB dynamic range, HPF, 4K switch
- Inputs 1/2 switchable to instrument level
- 10 balanced line outputs: +9 dBu / +24 dBu option for outputs 1/2 and 3/4
- 16-channel ADAT input @ 44.1 / 48 kHz (8 channels @ 96 kHz)
- 2-channel S/PDIF input (coaxial or optical)
- MIDI I/O (TRS)
- Two independently controlled stereo headphone outputs with 3 impedance settings (Standard / High Sensitivity / High Impedance)
- Talkback input with integrated Listen Mic Compressor (also usable as a line-in for stems with LMC)
- Legacy '4K' switch for sound coloration inspired by the SSL 4000 series
- Flexible internal and external clock options
- Stereo loopback with selectable loopback source
- SSL Production Pack software included
- Control via the free SSL 360° software application (incl. SSL18 Low Latency Mixer Tool)
- Dimensions (W x H x D): 482.6 x 43.6 x 294 mm
- Weight: 4 kg
- ADAT-In: Yes, 2 (up to 16 Mono Channels)
- BNC Word Clock: 0 In / 1 Out
- Design: Rack Enclosures
- Dimensions: (B x H x T): 482,6 x 43,6 x 294 mm
- Dynamic Range: 120 dB
- Headphone Output: 2x 6,3 mm Stereo Jack
- Hi-Z Input: 2x 6,3 mm Jack (Ch 1-2)
- Line in: 8x XLR/ Jack -Combo (Ch 1-8)
- Line out: 10x 6,3 mm Jack (balanced)
- MIDI I/O: 1 In / 1 Out
- Mic-In: 8x XLR/ Jack -Combo (Ch 1-8)
- Rack mounting: 19"/1U
- Resolution: 32 Bit
- S/PDIF Coaxial I/O: yes
- Sampling Rate: 192 kHz
- Subcategory: USB Audio Interface
- USB: yes
- Weight: 4 kg
