Active Diplexer LD Systems X223
Active Diplexer LD Systems X223Active Diplexer LD Systems X223

LD Systems X223

(6 Ratings)
  • Operation Mode: 2-way stereo or 3-way mono
  • Filter: Aditional switchable 40 Hz low-cut filter for both channels
  • Inputs and Outputs: Balanced XLR
  • Rack mounting: 19"/1U
  • Dimensions W/H/D: 482 x 44,5 x 153 mm
  • Weight: 2,6 kg
  • Bridgeable subwoofer output

LD Systems X223 · Active Diplexer

The LD Systems X-223 is a crossover in standard rack format (19"/1U), which enables distribution of the signal in 2 ways (stereo) or 3-way (mono). It is characterized by a rugged construction, high quality, stable controls and an integrated power supply which is not always standard in this price range.

Other features include a mono subwoofer output, separately adjustable crossover frequencies for the individual channels, Gain control for LF / HF and input gain, phase reverse switch, switchable 40 Hz high-pass filter and balanced XLR inputs and outputs. With the LD Systems X223 you have a crossover available that meets all professional requirements and is characterized by a high quality and excellent sound.

  • Bandwidth: 20Hz to 20kHz, +0.5 dB
  • Frequency response: <3 Hz to> 90kHz, + 0 / - 3dB
  • Dynamic Range: 106dB
  • THD + Noise: <0.004% at 4dBu, 1kHz
  • Inter Channel crosstalk: <- 80dB, 20Hz to 20kHz
  • Inputs: Female XLR
  • Max. Input Level: +22 dBu typical, balanced or unbalanced
  • Outputs: Male XLR
  • Max. Output Level:> + 21dBu balanced or unbalanced
  • Dimensions (W x H x D): 482 x 44.5 x 153 mm
  • Weight: 2.6 kg
